GHO60T15VH Germicidal UVC Lamp – 145W High Output Preheat-Start
The GHO60T15VH germicidal UVC lamp is a long-length, high-output, low-pressure ultraviolet lamp designed for demanding preheat-start disinfection systems that require very high UVC intensity and extended exposure length. Operating in the germicidal UVC range, this lamp is suited to enclosed air, water, and surface disinfection applications where maximum UV dose delivery is critical.
With its extended arc length and high electrical input, the GHO60T15VH delivers powerful and consistent UVC output, making it ideal for large HVAC installations, high-flow water treatment reactors, and industrial-scale UVC disinfection chambers. Designed for preheat-start operation, the lamp maintains stable germicidal performance throughout its extended rated service life when used with compatible control gear.
Key Features
-
High-output germicidal UVC lamp for intensive disinfection applications
-
Long-length design for extended UVC exposure and coverage
-
Preheat-start operation
-
High UVC output for increased microbial inactivation
-
Suitable for replacement use in compatible high-output UVC systems
Technical Specifications
Lamp Type: GHO60T15VH
Total Length: 2468 mm
Arc Length: 1554 mm
Lamp Diameter: 15 mm
Electrical Values:
-
Voltage: 180 V
-
Current: 0.8 A
-
Input Power: 145 W
UVC Output:
-
UVC Output Power: 50 W
-
UV Intensity @ 1 m: 425 µW/cm²
Rated Lamp Life: 12,000 hours
Applications
✔ Large-scale HVAC and ducted air disinfection systems
✔ High-flow commercial and industrial water treatment reactors
✔ Industrial UVC disinfection chambers
✔ Surface disinfection systems requiring high UV dose
✔ OEM and replacement use in high-output preheat-start UVC devices
Warnings and Safety
⚠ DANGER – Risk Group 3 Ultraviolet Product
This lamp emits high-intensity UVC radiation that can cause serious injury to skin and eyes.
-
Avoid direct exposure to UVC radiation
-
Use only in fully enclosed or shielded systems
-
Not intended for open or occupied environments
In the unlikely event of lamp breakage, ventilate the area for at least 30 minutes. Handle broken parts with gloves, place them in a sealed container, and dispose of them in accordance with local waste and recycling regulations. Do not use a vacuum cleaner.
Replacement Information
This lamp is intended for use as a replacement high-output germicidal UVC lamp in compatible preheat-start systems designed for the GHO60T15VH format. Always confirm electrical ratings, starter compatibility, and physical dimensions before installation.
